| Specification | Details |
|---|---|
| Model | CO-502W |
| Series | EVO Concept |
| Type | High-temperature undercounter dishwasher |
| Construction | AISI 304 stainless steel |
| Capacity | 30 racks/hour |
| Rack Size | 20″ × 20″ |
| Wash Cycles | 90 / 120 / 180 seconds |
| Wash Temperature | 150°F minimum |
| Rinse Temperature | 180°F |
| Dish Clearance | 15¼” |
| Wash Pump | ¾ HP |
| Water Consumption | 0.63 gal/rack |
| Wash Tank Capacity | 5.28 gal |
| Boiler Capacity | 1.85 gal |
| Booster Heater | Built-in, 70°F rise |
| Total Power | 3.5 kW |
| Electrical | 208–230V, 1-phase, 60 Hz |
| Dimensions (W × D × H) | 23⅝” × 23⅝” × 32¾” |
| Weight | Approx. 132 lb net / 172 lb crated |
| Water Protection | IPX4 |
| Noise Level | Under 65 dBA |
| Drain Pump | Built-in |
| Detergent Pump | Built-in |
| Rinse Aid Dispenser | Built-in |
| Pressure Gauge | Built-in |
