| Specification | Details |
|---|---|
| Model | DD24DI9N |
| Series | Series 9 |
| Type | Integrated Double DishDrawer™ |
| Installation | Built-in / panel-ready |
| Finish | Panel ready — custom cabinet panels |
| Capacity | 14 place settings |
| Capacity per drawer | 7 place settings |
| Drawers | 2 independently operating |
| Wash Programs | 6 |
| Wash Modifiers | Quick, Sanitize, Extra Dry |
| Noise Level | Approx. 43 dBA |
| Upper drawer plate capacity | Up to 12.25″ |
| Lower drawer plate capacity | Up to 11″ |
| Motor | BLDC SmartDrive™ |
| Drying | Fan-assisted |
| Wi-Fi | No |
| Flood Protection | Yes |
| Delay Start | Up to 12 hours |
| Voltage | 110–120V |
| Amperage | 10A |
| Frequency | 60 Hz |
| Water inlet | 3/8″ |
| Maximum inlet temperature | 140°F |
| Energy use | Approx. 263 kWh/year |
| Water consumption | Approx. 3.28 gal/cycle when both drawers operate |
